注射泵
1. 称重传感器用来监测注射泵的压力
| 规格参数Specifications | |
| 参数Specifications | 技术指标/technique |
| 量程Capacity | 1-25kg |
| 综合误差Comprehensive error | ±0.05%F.S |
| 精度等级Precision | C1 |
| 灵敏度Rated Output | 1.0±0.15mV/V |
| 零点输出Zero Balance | ±0.1 |
| 非线性non Linearity | ±0.02 %F.S |
| 滞后Hysteresis | ±0.02 %F.S |
| 重复性Repeatability | ±0.02 %F.S |
| 蠕变Creep | 0.05%F.S/30min |
| 温度灵敏度漂移Temp Effect On Output | 0.05%F.S/10℃ |
| 零点温度漂移Temp Effect On Zero | 0.05%F.S/10℃ |
| 输入阻抗Input Impedance | 1000±10Ω |
| 输出阻抗Output Impedance | 1000±10Ω |
| 绝缘电阻Insulation | ≥2000MΩ |
| 推荐激励电压Recommended Excitation | 3-10V(DC) |
| 温度补偿范围Compensated Temp Range | -10-40℃ |
| 工作温度范围Operation Temp Range | -20-60℃ |
| 安全过载Safe Overload | 150%F.S |
| 极限过载Ultimate Overload | 200%F.S |
| 电缆线尺寸Cable Size | Ø0.8x220mm（可定制） |
